Alu-Cab Gen 3-R Expedition Roof Tent

Gen 3-R Expedition Roof Top Tent

The Alu-Cab Gen 3-R is a premium expedition roof top tent designed for serious travel, combining rapid setup, rugged construction and modern comfort.

Built with a lightweight aluminium frame and streamlined hard-shell design, the Gen 3-R offers excellent aerodynamics while providing useful roof storage for equipment such as solar panels and kayaks. The insulated interior, 70mm high-density foam mattress and integrated ventilation help create a comfortable sleeping environment in all seasons.

The latest Gen 3-R also includes a heater vent as standard, making it particularly suited to colder climates, along with an integrated roof solar panel input.

The gas-strut-assisted opening system allows quick deployment, while the internal USB/USB-C charging points and LED lighting add everyday convenience.

Roof Cargo Load

The integrated roof cargo rails have a 50kg load rating.

Where the weight is positioned affects how easily the tent opens. Heavier items should be positioned towards the front of the tent, while lighter items such as solar panels are better positioned towards the rear.

Please note: Optional accessories such as the Drop Down Table and Reclining Bed Back Rest are not included and are available separately.

Features

• Lightweight aluminium frame
• Low-profile hard-shell design
• Roof storage suitable for items such as kayaks and solar panels
• Double-layer 400gsm canvas
• Hydrostatic head rating of >1000mm
• Streamlined aerodynamic profile
• Gas-strut-assisted pop-up opening
• 50kg roof cargo rail load rating
• 70mm high-density foam mattress
• Zip-off mattress cover
• Raised ventilation air vent
• 3D breathable mesh under-mattress
• Standard heater vent for cold-weather use
• Zippable rear awning
• Quick-release telescopic ladder
• Wide, angled ladder rungs
• Ladder can be mounted to the side or rear of the tent
• Ladder can be stored inside the tent
• Internal storage pockets
• Internal USB and USB-C power points
• Integrated internal LED lighting
• Integrated roof solar panel input
• High-density closed-cell foam insulation in the roof and base

What's Included?

• 1 × Gen 3-R Roof Top Tent with LED lighting and charging
• 1 × Charging lead with cigarette lighter plug
• 1 × Mattress
• 1 × Anti-condensation mat
• 1 × Telescopic ladder
• 1 × Set of 4 mounting brackets with fixings
• Installation instructions

Specifications

Tent Type: Hard-shell expedition roof top tent

Construction: Lightweight aluminium frame

Fabric: Double-layer 400gsm canvas

Hydrostatic Head Rating: >1000mm

Mattress: 70mm high-density foam

Roof Cargo Load Rating: 50kg

Closed Interior Dimensions: 2100mm L × 1300mm W

Closed Exterior Dimensions: 2300mm L × 1400mm W × 210mm front / 280mm rear H

Open Interior Dimensions: 2100mm L × 1300mm W × 1600mm H

Open Exterior Dimensions: 2300mm L × 1400mm W × approx. 2000mm H

Weight: Approx. 76kg excluding mattress and ladder

Mattress Weight: Approx. 3kg / 7lbs

Materials: Aluminium frame, hard-shell construction and 400gsm canvas

Power: Internal USB and USB-C power points with integrated solar input

Lighting: Integrated LED lighting

Installation

The Gen 3-R should be mounted onto 2 × 1450mm long roof bars, such as suitable Front Runner or Alu-Cab roof bars.

The supplied mounting kit includes 4 mounting brackets and fixings.

Important Information

The 50kg roof cargo rating applies to the cargo rails, but the positioning of the load is important. Heavy items should be kept towards the front of the tent to make opening easier. Lighter items, such as solar panels, should be positioned towards the rear.

Optional accessories including the Drop Down Table and Reclining Bed Back Rest are not included.

FAQs

• How many people does the Gen 3-R sleep?
  The Gen 3-R is recommended for 2 people.
• What roof bars are required?
  The tent should be mounted on 2 × 1450mm long roof bars, such as suitable Front Runner or Alu-Cab bars.
• Can I carry gear on top of the tent?
  Yes. The roof cargo rails have a 50kg load rating. Heavier items should be positioned towards the front and lighter items towards the rear.
• Are the Drop Down Table and Reclining Bed Back Rest included?
  No. These are optional extras and are available separately.
• How will the tent be delivered?
  The Gen 3-R is delivered on a pallet. Due to its size and weight, delivery requires suitable forklift access. Please contact us if you have any questions about delivery.
